Payment & Shipping Terms:
|CNC Control System:||SIEMENS, FANUC, GSK, According To Customer Request||Voltage:||380V, 440V, 415V, 220V, Etc|
|Weight Of Machining Part:||15T||After-sale Service Of Roll Lathe:||Engineers Are Available For Oversea Machine Installation And Commissioning|
|Metal Lathe Type:||Vertical Type With 2 Columns||Metal Lathe Condition:||New|
cnc vertical turret lathe,
vtl lathe machine
Vertical Metal Lathe Machine with double columns for turning gear case
1. Application of Vertical Lathe: Professionally used for can utilize high-speed steel and carbide cutting tools to finish rough or finish turning process for not only the non-ferrous metals like various structure steels, casting steels and irons, cylinders, Bearing, etc but also the external,internal cylindrical , conical, spherical surfaces, thread of non-metal materials and all kinds of the surface of curve rotary body.
Facing Lathe, Flange Lathe, Horizontal Lathe Machine,CNC Heavy-duty horizontal lathe, Roll Turning Lathe, Propeller turning lathe, Conventional Lathe, CNC End-Face lathe, automobile wheel hub lathe, large floor-type lathe , CNC Drilling Lathe Machine and CNC milling Lathe machine are the leading products of the company. These machines are widely applied to the energy & transport, mining &metallurgy, railways & shipbuilding, pipe molding, automobile parts, wind power chemical industry and other machinery manufacturing industries.
We provide the perfect CAD/CAM information processing and 3D design software, combined with domestic higher-educational institutions to form a science and technology association. We averagely launch more than 5 high technical patent products annually.
2. OUR ADVANTAGES & FEATURES about CNC Vertcial LATHE , Conventional Vertical Lathe:
1. More than 50 years experience in designing and manufacturing customized Vertcial Lathe, CNC Vertical Lathe, Pipe Turning Lathe, Pipe Threading CNC Lathe, Horizontal Lathe, Roll turning lathe, lathe machine, horizontal CNC lathe, Conventional vertical lathe , Conventional Lathe and other machine tools.
2. We have our own FOUNDRY, which can control and guarantee the castings quality very well.
3. We have our own annealling furnace to do surface treatment of QUENCHING and HARDENING.
4. High torque capacity of worktable of lathe machine
5. Zero backlash with ball screw.
6. Rough & finish machining is achieved in the cnc lathe machine with SIEMENS or FANUC cnc control system
Exported Countries :
Russia, Georgia, Thailand, Azerbaijan, Ethiopia, Argentina, Australia, Turkey, Italy, Norway, India, Iran, Inodesia, Brazil, Panama, Colombia, etc
3. Technical Parameters of Big Vertical Lathe
|Maximum diameter of workpiece||1250 mm|
|Maximum height of work-piece||1000 mm|
|Maximum weight of workpiece||3T|
|Work-Table Diameter||1250 mm|
|Table steps of speeds||stepless|
|Range of speeds of rotation||10 ~ 160r/min|
|4 Positions cutting tool||Manual type|
|Fast Moving Speed of X,Y Axis||3000 mm/min|
|Power of Main Motor(Variable Frequency)||18.5 KW|
|Overall Size of Machine||2460mm*2380mm*3000 mm|
|CNC Control System||SIEMENS 808D, FANUC Control|
Remarks: The above technical parameters of Vertical Lathe Machine is the standard specifications, we are also specialized in manufacturing customized lathe.
4. After-sale Service
1. Engineers are available for Vertical lathe machine installation , commissioning and training at the user factory.
2. Machine accessories like chuck jaws, gears, bearings, cutting tools etc can be provided immediately by Fedex, DHL, etc to prevent the production termination.
3. The quality warranty of CNC Vertical Lathe,Heavy Duty Horizontal Lathe, Lathe Machine, CNC Lathe is 12 months.
For more details, please feel free to contact us.
Thank you for attention.
Tag: Vertcial cnc lathe machine, cnc lathe, vertical lathe, horizontal lathe, Metal Lathe Machine
Contact Person: Anna Sun
