Universal Gear Head Lathe Machine Stable Running Long Working Life

Universal Gear Head Lathe Machine Stable Running Long Working Life
Universal Gear Head Lathe Machine Stable Running Long Working Life Universal Gear Head Lathe Machine Stable Running Long Working Life Universal Gear Head Lathe Machine Stable Running Long Working Life Universal Gear Head Lathe Machine Stable Running Long Working Life

Large Image :  Universal Gear Head Lathe Machine Stable Running Long Working Life

Product Details:

Place of Origin: Qingdao,China
Brand Name: NTM or customized lathe is also available
Certification: ISO9001, BV, CE, EAC etc
Model Number: CK64160 CK64200 CK64250 CK64300

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden Box Package
Delivery Time: 90 days
Payment Terms: T/T
Supply Ability: 200 sets/ year
Detailed Product Description
Application Of Facing Lathe Machine: Machining Metal Flange, HDPE Flange, Aluminum Mold Warranty Of Lathe Machine: 12 Months
Usage: Turning The Facing, Threading Inner Hole, Tapping Machine Tool: 4 Positions Automatic Electrical Rotation Cutting Tool
High Light:

precision metal lathe

,

steel lathe machine

Universal Big Head CNC Turning Facing in Lathe ,Flange Lathe

For Turning Flange, Ship Propeller, Auto Spare Parts, Alloy wheel,Tube Plate,Tire Mold,Wheel Hub Turbine,Diameter 2000 mm Flange,Oil Pan,etc

Lathe Machine Special Features:


1. More than 50 years' experience in machinery industry since 1960s.

2. Manual Control,FANUC ,SIMENS or Chinese Brand system (Optional)

3. Base adopts triangular guide design

4. Reasonable structure

5. High performance with low cost



6. We have our own foundry which can control the quality strictly.



7. All castings are do surface heat treatment such as QUENCHING AND TEMPERING to guarantee the high rigidity and stability of lathe machine.

8. Maximize Customer's Profitability under the minimum invest cost compared with other competitors.

9. We are specialized in designing and manufacturing customized lathes for over 50 years , if you have special request and demands, please feel free to contact us.

Application of Facing In Lathe, Flange Lathe, Horizontal Lathe:



Heavy Duty CNC Lathe Machine is a special-purpose heavy-duty CNC face lathe and it is suitable for turning the internal/external cylindrical surface, conical surface, end face and so on with large-diameter for all kinds of workpieces .
This lathe is reasonable in structure and strong in rigidity with large power and good stability, and what's more, it's beautiful in appearance and easy for operation, really the ideal product for processing all kinds of large-diameter workpieces.

The feed system of this lathe adopts frequency control motor to realize the stepless speed regulation. This makes the choice of feed rate more convenient.

2. Standard Technical Parametes of Facing In Lathe, Flange Lathe, Facing In Lathe



Specifications of Facing in Lathe
Name Unit CK64125 CK64160 CK61200 CK64250 CK64300
Swing Diameter over Machine Bed mm φ1250mm φ1600mm φ2000mm φ2500mm φ3000
Chuck Diameter mm φ1000mm φ1250mm φ1600mm φ2000mm φ2500mm
Chuck-jaw seat length mm Embedded Embedded 500mm 500mm 500mm
Work-piece Length mm 500mm 750mm 750mm 1000mm 1000mm
Work-piece Weight T 2T 2T 3T 3T 5T
Spindle Diameter mm φ190mm φ200mm φ220mm φ220mm φ260mm
Spindle Speed r/min 10-200 r/min 4-160 r/min 4-160 r/min 3-106 r/min 3-106 r/min
X Axis Stroke mm 625mm 800mm` 1000mm 1250mm 1500mm
Z Axis Stroke mm 500mm 750mm 1000mm 1000mm 1000mm
X Axis Rapid Feed Speed mm/min 2500mm/min 2500mm/min 2500mm/min 2000mm/min 2000mm/min
Z Axis Rapid Feed Speed mm/min 2000mm/min 2000mm/min 2000mm/min 2000mm/min 2000mm/min
Cutting Tool Carriage Size   240*240 280*280 300*300 300*300 300*300
Cutting Tool Shank Size mm 32*32mm 40*40mm 40*40mm 40*40mm 40*40mm
Feed Control   Servo Motor Servo Motor Servo Motor Servo Motor Servo Motor
Motor Parameters
Main Motor Power KW 15KW 18.5KW 18.5KW 22KW 37KW
Feed Motor of Z Axis KW 2.3KW 2.3KW 2.3KW 2.3KW 2.3KW
Feed Motor of X Axis KW 2.3KW 5.5KW 5.5KW 5.5KW 5.5KW
Lubrication Motor Power KW 0.37KW 0.37KW 0.37KW 0.55KW 0.55KW
Machine Accuracy
Cylindricity mm 0.03/300mm 0.03/300mm 0.03/300mm 0.03/300mm 0.03/300mm
Flatness mm 0.03/300mm 0.03/300mm 0.03/300mm 0.03/300mm 0.03/300mm
Roughness Ra Ra3.2 Ra3.2 Ra3.2 Ra3.2 Ra3.2
Machine Dimensions mm 3180*1910*1870 3940*1980*1900 4190*2670*2450 4250*2770*2800 4400*3300*3300
Machine Weight T 6T 9.5T 11T 12.5T 15T





3. After-sale Service of Facing in Lathe


1. We provide professional technical training for users' operators and maintenance staff to enable them to properly use and operate the lathe and carry out normal maintenance.

2. Warranty period: One year after acceptance of the lathe.

3. In case of any quality problem found during operation, the factory will dispatch personnel to the user's location within 48 hours (domestic users) & within 3 days (Foreign Customer) and the technical staff won't leave before resolving the malfuntion.

4. The company will freely provide different electrical and mechanical parts for the purchased lathe timely within warranty period.

5. The company will provide lifetime guarantee for the consulting services in terms of application, maintenance, repair, renovation, etc of equipments.


For more details, please feel free to contact us. Thanks!





Universal Gear Head Lathe Machine Stable Running Long Working Life 0

Universal Gear Head Lathe Machine Stable Running Long Working Life 1
